When a trolley bus reaches a road junction, wire-switches, installed on the overhead conductor cables, control its direction of travel. Switches may be in the default “straight-through” position or in “turnout” position. As a bus passes a switch in turnout position, a sensor mounted on the overhead cables detects the presence of the current collector. The control system then resets the switch to the default position.

Customer value

• Exceptional reliability in a harsh outdoor environment
• Automatic operation with optimal space utilization
• Elimination of switching errors during year-round operation
• Significantly reduced maintenance costs

Advantages of through-beam sensor LLK-3030-00#-502

• All-electronic device with sensing range up to 12,000 mm
• Large sensing range available in physically small sensor
• Exceptional resistance to vibration during operation, IP67
