Short Specifications

TRR-C23PA-PMK-101

Operating range 20...4200 mm
Switching frequency max. 1500 Hz
Supply voltage 10...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment 3/4-turn pot.
Connection PVC, 2 m, 4 wire
Housing size [mm] 20 x 30 (C23)
Enclosure rating IP 67
Housing material ABS
Sensitivity Range Adjustm 30...5000 mm
Temperature range -25...+65°C
Light source LED, red 630 nm
Interface Standard output
Operating principle Transparent reflex
Sensing range max. 10...5000 mm

Downloads

Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf

3D CAD Library

Transparent object Transparent reflex 20 x 30 (C23) 20...4200 mm ABS 3/4 turn pot. LED, red 630 nm

SKU: TRR-C23PA-PMK-101

Connection: PVC, 2 m, 4 wire
Output: Light-on + Dark-on
Polarity: NPN
Price:
Sale price$70.60
Stock:
In stock

Estimated Delivery Time 2-3 weeks
