Short Specifications
LRK-3031-302
| Operating range | 2000 mm |
| Switching frequency max. | 1000 Hz |
| Supply voltage | 10...36 |
| Polarity | NPN |
| Output | Dark-on |
| Sensitivity adjustment | 12-turn pot. |
| Connection | PVC, 2 m, 3 wire |
| Housing size [mm] | 30 x 30 |
| Enclosure rating | IP 67 |
| Housing material | PBTP (Crastin) |
| Temperature range | -25...+55°C |
| Light source | LED, red 660 nm |
| Interface | Standard output |
| Operating principle | Reflex |
| Sensing range max. | 0 |
