LFK-4040-103
| Operating range | 150 mm |
| Switching frequency max. | 1000 Hz |
| Supply voltage | 10...36 |
| Polarity | PNP |
| Output | Light-on + Dark-on |
| Sensitivity adjustment | 20-turn pot. |
| Connection | PVC, 3 m, 4 wire |
| Housing size [mm] | 40 x 40 |
| Enclosure rating | IP 67 |
| Housing material | PBTP (Crastin) |
| Temperature range | -25...+55°C |
| Light source | LED, infrared 880 nm |
| Interface | Standard output |
| Operating principle | Fiber amplifier |
| Sensing range max. | 0 |
| Type | Format |
| Datasheet |
|
| Operating Manual |
|
| CE Certificate |
|
| UKCA Certificate |
|
Photoelectrics Sensor Standard-Fiber-amplifier-40-40-150-mm-PBTP-Crastin-20-turn-pot-LED-infrared-880-nm LFK-4040-103
Standard Fiber amplifier 40 x 40 150 mm PBTP (Crastin) 20 turn pot. LED, infrared 880 nm
SKU: LFK-4040-103
Regular price
From $120.25
Secure Checkout
