Short Specifications

LTR-M18PA-PMK-101

Operating range 5...1000 mm
Switching frequency max. 1500 Hz
Supply voltage 10...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment 3/4-turn pot.
Connection PVC, 2 m, 4 wire
Housing size [mm] M18
Enclosure rating IP 67
Housing material ABS
Sensitivity Range Adjustm 30...1200 mm
Temperature range -25...+65°C
Light source LED, red 630 nm
Interface Standard output
Operating principle Diffuse
Sensing range max. 3...1200 mm

Downloads

Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf

3D CAD Library

Standard Diffuse M18 5...1000 mm ABS 3/4 turn pot. LED, red 630 nm

SKU: LTR-M18PA-PMK-101

Connection: PVC, 2 m, 4 wire
Output: Light-on + Dark-on
Polarity: NPN
Price:
Sale price$49.95
Stock:
Re-stocking soon

Estimated Delivery Time 2-3 weeks
