Short Specifications

LHR-C23PA-PMK-101

Operating range 15...250 mm
Switching frequency max. 1000 Hz
Supply voltage 10...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment 3/4-turn pot.
Connection PVC, 2 m, 4 wire
Housing size [mm] 20 x 30 (C23)
Enclosure rating IP 67
Housing material ABS
Sensitivity Range Adjustm 30...300 mm
Temperature range -25...+65°C
Light source Pinpoint LED, red 640 nm
Interface Standard output
Operating principle Background suppression
Sensing range max. 10...300 mm

Downloads

Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf

3D CAD Library

Standard Background suppression 20 x 30 (C23) 15...250 mm ABS 3/4 turn pot. Pinpoint LED, red 640 nm

SKU: LHR-C23PA-PMK-101

Connection: PVC, 2 m, 4 wire
Output: Light-on + Dark-on
Polarity: NPN
Price:
Sale price$66.30
Stock:
In stock

Estimated Delivery Time 2-3 weeks
