LTI-M05MH-NMK-403
| Operating range | 0...25 mm |
| Switching frequency max. | 250 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Light-on |
| Sensitivity adjustment | 15...30 mm, IO-Link |
| Connection | PVC, 2 m, 3 wire |
| Housing size [mm] | M5 |
| Enclosure rating | IP 67 |
| Housing material | Stainless-steel V2A |
| Temperature range | 0...+55°C |
| Light source | LED, infrared 880 nm |
| Interface | IO-Link |
| Operating principle | Diffuse |
| Sensing range max. | 0...30 mm |
| Type | Format |
| Datasheet |
|
| IODD zip |
|
| CE Certificate |
|
| UKCA Certificate |
|
Photoelectrics Sensor Miniature-Diffuse-M5-025-mm-Stainless-steel-V2A-1530-mm-IO-Link-LED-infrared-880-nm LTI-M05MH-NMK-403
Miniature Diffuse M5 0...25 mm Stainless steel V2A 15...30 mm, IO Link LED, infrared 880 nm
SKU: LTI-M05MH-NMK-403
Regular price
$229.39
Secure Checkout
