Short Specifications

DW-AD-703-M18-BAS

Operating range 5 mm
Switching frequency max. 100 Hz
Supply voltage 10...30
Operating pressure [bar] ≤ 60 bar
Polarity PNP
Output Normally Open (NO)/IO-Link
Connection PUR, 2 m, 3 wire
Housing size [mm] M18
Enclosure rating IP 68 / IP 69K
Housing material Stainless-steel V2A
Temperature range -25...+70°C
Sensor Height 51 mm
Mounting Embeddable
Interface IO-Link

Downloads

Type Format
Datasheet pdf
IODD zip pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf

3D CAD Library

Basic Full Inox Series 700 M18 Embeddable 5 mm

SKU: DW-AD-703-M18-BAS

Connection: PUR, 2 m, 3 wire
Polarity and Output: PNP|Normally Open (NO)/IO-Link
Sensor length: 51 mm
Price:
Sale price$67.20
Stock:
Re-stocking soon

Estimated Delivery Time 2-3 weeks
