DW-AD-503-C8
| Operating range | 3 mm |
| Switching frequency max. | 1000 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Normally Open (NO)/IO-Link |
| Connection | PVC, 2 m, 3 wire |
| Housing size [mm] | 8 x 8 (C8) |
| Enclosure rating | IP 67 |
| Housing material | Chrome-plated brass |
| Temperature range | -25...+70°C |
| Sensor Height | 40 mm |
| Mounting | Quasi-embeddable |
| Interface | IO-Link |
| Type | Format |
| Datasheet |
|
| IODD zip |
|
| CE Certificate |
|
| UKCA Certificate |
|
| UL Certificate |
|
Inductives Sensor Basic-Extra-Distance-Series-500-8-8-C8-Quasi-embeddable-3-mm DW-AD-503-C8
Basic Extra Distance Series 500 8 x 8 (C8) Quasi embeddable 3 mm
SKU: DW-AD-503-C8
Regular price
From $124.75
Secure Checkout
Need help? Click here to contact an expert
DW-AD-503-C8
| Operating range | 3 mm |
| Switching frequency max. | 1000 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Normally Open (NO)/IO-Link |
| Connection | PVC, 2 m, 3 wire |
| Housing size [mm] | 8 x 8 (C8) |
| Enclosure rating | IP 67 |
| Housing material | Chrome-plated brass |
| Temperature range | -25...+70°C |
| Sensor Height | 40 mm |
| Mounting | Quasi-embeddable |
| Interface | IO-Link |
| Type | Format |
| Datasheet |
|
| IODD zip |
|
| CE Certificate |
|
| UKCA Certificate |
|
| UL Certificate |
|
Inductives Sensor Basic-Extra-Distance-Series-500-8-8-C8-Quasi-embeddable-3-mm DW-AD-503-C8
