Short Specifications


Operating range 20 mm
Switching frequency max. 125 Hz
Supply voltage 10...30
Operating pressure [bar] ≤ 40 bar
Polarity PNP
Output Normally Open (NO)/IO-Link
Connection M12 4-pin
Housing size [mm] M18
Enclosure rating IP 68 / IP 69K
Housing material Stainless-steel V2A
Temperature range -25...+85°C
Sensor Height 63.5 mm
Mounting Embeddable
Interface IO-Link


Type Format
Datasheet pdf
IODD zip pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf

3D CAD Library

Extreme Full Inox Series 700 M18 Embeddable 20 mm

SKU: DW-AS-703-M30-528

Connection: M12 4-pin
Polarity and Output: PNP|Normally Open (NO)/IO-Link
Sensor length: 63.5 mm

Estimated Delivery Time 2-3 weeks
