DW-AD-603-M12
| Operating range | 2 mm |
| Switching frequency max. | 3000 Hz |
| Supply voltage | 10...30 |
| Polarity | PNP |
| Output | Normally Open (NO)/IO-Link |
| Connection | PVC, 2 m, 3 wire |
| Housing size [mm] | M12 |
| Enclosure rating | IP 67 |
| Housing material | Nickel-plated brass |
| Temperature range | -25...+70°C |
| Sensor Height | 50 mm |
| Mounting | Embeddable |
| Interface | IO-Link |
| Type | Format |
| Datasheet |
|
| IODD zip |
|
| CE Certificate |
|
| UKCA Certificate |
|
| UL Certificate |
|
Inductives Sensor Basic-Classics-Series-600-M12-Embeddable-2-mm DW-AD-603-M12
Basic Classics Series 600 M12 Embeddable 2 mm
SKU: DW-AD-603-M12
Regular price
From $39.45
